| Technical Specifacation | |
| Abmessungen | 680*550*440mm |
| Weight | 68kg |
| Drive Form | Swerve Steering Motor Drive |
| Material | Aluminium Alloy |
| Ground Clearance | 120mm |
| Wheel Track | 400mm |
| Wheel Base | 420mm |
| Wheel Diameter | 9.5 inch/240mm |
| Motor | 350Wx4, Servo Motor |
| Battery | 36V/30AH |
| Charging Time | 4-5h |
| Charging Method | 36V/10A Manual Charging/ |
| External Power Supply | Auto Charging |
| Braking Method | 24V/15A-12V/15A |
| Parking Method | Motor Braking |
| Payload | Motor Parking |
| Speed | 80KG |
| Running Mileage | 5.4km/h |
| Wading Depth | 40km |
| Max Climbing Capacity | 100mm |
| Span Width | 15° with full load |
| Obstacle Surmounting Height | 120mm with full load |
| IP Rating | 25mm with full load |
| Communication Interface | IP33 |
| Gewicht | 1 kg |
|---|
Schreibe die erste Bewertung für „OMNI OM400 Full Scene Application Omnidirectional UGV“
