פתרון רחפן RTK מערכת תחנת בסיס GPS ברמת דיוק גבוהה למדידת מיפוי מיקום לווייני

RTK drone using Real-time kinematic (RTK) positioning is a satellite navigation technique used to enhance the precision of position data derived from satellite-based positioning systems (global navigation satellite systems, GNSS) such as GPS, GLONASS, Galileo, and BeiDou. It uses measurements of the phase of the signal’s carrier wave in addition to the information content of the signal and relies on a single reference station or interpolated virtual station to provide real-time corrections, providing up to centimetre-level accuracy. With reference to GPS in particular, the system is commonly referred to as carrier-phase enhancement, or CPGPS. It has applications in land survey, hydrographic survey, and in unmanned aerial vehicle navigation.

Two working modes:

                                                                               RTK broadcast mode:

Drone single point mode:

RTK-BASE encapsulates the received RTK raw data with mavlink and transmits hotspots via WIFI. The user can directly communicate with the drone through the mobile phone or computer ground station, and the drone can also directly receive RTK and mavlink interaction. data.

Built-in WEB server

Through the WIFI, you can access the RTK-BASE WEB management interface. Through the WEB management interface, you can view the RTK signal status and power information in real time, and can configure the RTK operation mode, parameters and P9 data transmission, and also perform RTK-BASE. Upgrade restore operation

סוללה מובנית

Built-in 7000mah 7.4V capacity battery and PMU battery management chip, can work continuously for 12 hours by internal battery, support 12V direct charging, and easily expand external solar charging, achieve 7X24 hours operation

Integrated OLED display IP65 protection

CUAV RTK-BASE integrates an OLED display that displays the current operating mode, battery status, RTK status, and associated drone status via the oled display. With IP65 protection, it can be used in harsh environments.

Built-in 16G storage space, can be used to store base station RTK raw observation data through post-expansion, for post-difference calculation, etc.

Covering hundreds of application scenarios

מפרט טכני:

Size (cm):28*20*15cm

 weight: 2KG

Package including:

1)C-RTK BASE+accesorry

2) C-RTK BASE+RTK+P900  data transmission
